FLEXIDOME panoramic 5100i: snapshot URL returns fisheye (round).jpg image instead of de-warped image

🕒 This procedure takes in average ~ 6 min to complete

Possible causes and solution(s)

• Causes

By querying the camera on http://CameraIp/snap.jpg, it returns the fisheye (round) .jpg image instead of de-warped image

Is there a way to request for the panoramic camera de-warped snapshot via URL?

• Solution

The camera must be setup as edge dewraping mode on the web interface.
Configuration → Camera → Installer Menu
- Application variant : FLEXIDOME panoramic 5100i - DEWRAP

Try the following URLs:

• Video input 1:
  • https://IPaddress/snap.jpg?JpegCam=1
• Video input 2:
  • https://IPaddress/snap.jpg?JpegCam=2
• Video input 3:
  • https://IPaddress/snap.jpg?JpegCam=3

*Where IPaddress is the IP Address of your FLEXIDOME panoramic 5100i Bosch camera

Also, the following Tech Note covers this topic and might be useful for you:

• https://resources-boschescurity-cdn-hre9eue8h0fefmcd.a02.azurefd.net/public/documents/__Application_note_enUS_1552286731.pdf
