FLEXIDOME panoramic 5100i: snapshot URL returns fisheye (round).jpg image instead of de-warped image


🕒 This procedure takes in average ~ 6 min to complete

Possible causes and solution(s)

  • Causes

By querying the camera on http://CameraIp/snap.jpg, it returns the fisheye (round) .jpg image instead of de-warped image


Is there a way to request for the panoramic camera de-warped snapshot via URL?


  • Solution

The camera must be setup as edge dewraping mode on the web interface.
Configuration → Camera → Installer Menu
- Application variant : FLEXIDOME panoramic 5100i - DEWRAP

Try the following URLs:

  • Video input 1:https://IPaddress/snap.jpg?JpegCam=1

  • Video input 2:https://IPaddress/snap.jpg?JpegCam=2

  • Video input 3:https://IPaddress/snap.jpg?JpegCam=3

*Where IPaddress is the IP Address of your FLEXIDOME panoramic 5100i Bosch camera


(tick) Also, the following Tech Note covers this topic and might be useful for you:
